5-29
5.4 Removing the SMR Assembly
1. First remove the 4 screw covers and then unscrew the 4 M3×8 screws.
2. Pull the left- and right-side boards outwards. Be sure to place the rubber ring in position
when reassembling the right-side board.
Right-side
Left-side board
