3-6
NOTE
z You can use an NIBP simulator to replace the balloon pump and the reference
manometer to perform the test.
z You can use an appropriate cylinder and a cuff instead of the rigid vessel.
NIBP Leakage Test
NOTE
z You should perform NIBP accuracy test and make sure the test result is pass prior
to NIBP leakage test.
Tools required:
NIBP cuff for adult patient
Appropriate tubing
Cylinder
Follow this procedure to perform the test:
1. Set [Patient Cat.] to [Adu].
2. Connect the NIBP cuff with the NIBP connector on the monitor.
3. Apply the cuff to the cylinder as shown below.
4. Select [Main Menu]→ [Maintenance>>]→ [NIBP Leakage Test]. The message
[Leakage Testing…] is displayed in the NIBP parameter area.
5. The cuff automatically deflates after 20s, which means NIBP leakage test is
completed.If no message is displayed in the NIBP parameter area, it indicates that the
system has no leakage. If the message [NIBP Pneumatic Leak] is displayed, it indicates
that the system may have a leakage. In this case, check if all connections are good and
the cuff and tubing have no leakage. Perform the test again after making sure all
connections are good and the cuff and tubing have no leakage.
Air tubing
Monitor
Connector for
NIBP cuff
Cylinder
Cuff
