Mindray BeneView T5 Service Manual

3-34
Block the gas inlet of the module or watertrap. The sidestream
CO
2
flowrate is slower than 10ml/min and an alarm of CO
2
Filterline Err is given. It indicates that there is no leakage.
Yes N o
The displayed CO
2
value is within 6±0.05％.
Yes N o
Miscrostream CO
2
test and calibration
Block the gas inlet of the module or watertrap. An alarm of CO
2
Filterline Err is given. It indicates that there is no leakage.
Yes N o
The displayed CO
2
value is within 6.0±0.3％
Yes N o
AG test and calibration
When AG flowrate is slower than 10ml/min, an alarm of AG
Airway Occluded is given. It indicates that there is no leakage.
Yes N o
The fan inside the AG module works properly. Yes No
The measurement accuracy of CO
2
, N
2
O, O
2
and AA (AA
represents an anaesthetic agent) meets the product specifications
in the Operator’s Manual.
Yes N o
ICG test
The measured results are as follows: HR=60±2 bpm,
VI=61±4/1000s, TFC=32±2/kOhms.
Yes N o
The measured results are as follows: HR=70±2 bpm, VI=48±4
/1000s, TFC=32±2 / kOhms.
Yes N o
BIS test (you can select either method to perform the test)
Method 1: The BIS value measured on healthy, wide-awake
adult is within 80-100.
Yes N o
Method 2: Connect to the BIS simulator to perform a cyclic
impedance check. The EEG wave and BIS numeric are displayed
on the monitor.
Yes N o
RM test
The displayed TV is within 500±50ml and RR is within
20±1rpm.
Yes N o
CCO/SvO
2
test
The CCO/SvO
2
numerics displayed on the patient monitor and
Vigilance monitor are consistent.
Yes N o
The waves (at the ECG signal output port) displayed on the
oscillograph are consistent with the ECG calibration waves
displayed on the monitor screen.
Yes N o
The amplitude of electrical level at the signal output port of
MAP, CVP and SpO
2
are 5±0.25V, 5±0.25V and 10±0.5V
Yes N o
