S
truct
ure and
Assembly/Disas
sembly 9-
41
4.
Unscrew six M4 X
12 scre
ws.
5.
Remove se
micircle-shaped
cover
.
6.
Remove the
holders on b
oth sides. Press the
clips
inwards.
Lift t
he holders t
o both sides t
o
remove t
hem.
Note:
The
metal
part
is
inserted
in the ho
le of
the
plastic
pa
rt.
The
damage of
the
display
’s
rear cover
may occur if r
emoved by
force.
