Accuracy drift Meet the requirement for measurement accuracy within 6 hours
Apnea alarm time 10 s, 15 s, 20 s, 25 s, 30 s, 35 s, 40 s
Refreshing rate 1 s
Response time
Using the DRYLINE™ water trap and neonatal DRYLINE™ sampling line (2.5m):
120 ml/min 90 ml/min 70 ml/min
CO
2
≤4S s ≤ 4.5 s ≤5 s
N
2
O ≤4.2 s ≤5 s ≤5.5 s
O
2
≤4 s ≤5 s ≤6 s
Hal, Iso, Sev, Enf ≤4.4 s ≤5.2 s ≤6 s
Des ≤4.4 s ≤5 s ≤6 s
Using the DRYLINE™ water trap and adult DRYLINE™ sampling line (2.5m)
200 ml/min 150 ml/min 120 ml/min
CO
2
≤4.2 s ≤4.8 s ≤5.5 s
N
2
O ≤4.3 s ≤5 s ≤5.8 s
O
2
≤4 s ≤4.6 s ≤5.5 s
Hal, Iso, Sev, Enf, Des ≤4.5 s ≤5.2 s ≤6 s
Anesthetic agent limit
Primary anesthetic agent
In full accuracy mode: 0.15%,
Second anesthetic agent:
In full accuracy mode: 0.3% or 5% REL (10% in ISO accuracy mode) of primary agent if
primary agent is greater than 10%
Effect of interference gases on AG measurements
Gas Concentration(%)
Quantitive effect(%ABS)
3)
CO
2
N
2
O Agent
1)
O
2
CO
2
/ / 0.1 0 0.2
N
2
O / 0.1 / 0.1 0.2
Agent
1) 2)
/ 0.1
0.1
5
）
0.1
4
）
1.0
Xenon <100% 0.1 0 0 /
Helium <50% 0.1 0 0 /
Ethanol <0.1% 0 0 0 /
Acetone <1% 0.1 0.1 0 /
Methane <1% 0.1 0.1 0 /
Saturated Isopropanol vapour / 0.1 0 0 /
O
2
/ 0.1 0.1 0.1 /
1) Agent represents one of Des, Iso, Enf, Sev, and Hal.
2) Multiple agent interference on CO
2
, N
2
O and O
2
is typically the same as single agent interference.
3) For CO
2
, N
2
O and Agents, maximum interference from each gas at concentrations within specified accuracy ranges for each
gas. The total interference of all gases is never larger than 5%
REL
.
4) Applicable to type A AG module, representing the interference effect of secondary anesthetic agents on primary
anesthetic agent.
5) Measurement interference to type M AG module originates from the applied anesthetic agent that is configured manually.
