ECG/RESP Monitoring
11-18
NOTE
z If the filter method of the ECG waveform is set to a non-diagnostic mode,
only the NOTCH option ON is active and the monitor filters the signals of
the power line frequency; if the filter method is set to the diagnostic
mode, two NOTCH options, both ON and OFF, are active, and the system
sets the NOTCH to OFF automatically.
CASCADE
ECG cascade
ON: The monitor displays the waveform of each channel in
two lines.
OFF: The monitor displays the waveform of each channel
in one line.
The CASCADE can be turned ON only if the monitor is
set to NORMAL DISPLAY mode and the SCAN TYPE is
set to REFRESH.
DEFIB SYNC
Defibrillator synchronization
ON: The function of defibrillation is enabled;
OFF: The function of defibrillation is disabled.
If the function of defibrillator synchronization is enabled and the ventricular
defibrillation is applied, 100ms/+5V defibrillator synchronization signals will be
output through the auxiliary output connector to the defibrillation equipment.
When the defibrillator synchronization is enabled, the “Defib Sync ON!” message is
displayed in the prompt information area, at the lower left corner of the screen. This
message disappears after 10 seconds. Besides, the technical alarms area also shows
the “DEFIB SYNC ON” message.
NOTE
z Defibrillator synchronization can be enabled only if the AUX OUTPUT in
the USER MAINTAIN menu is set to DEFIB. SYN. Otherwise, this function
is disabled.
z When the monitor is started, DEFIB SYNC is set to OFF as a default.
