ECG/RESP Monitoring
11-35
For details about this menu, refer to 11.3 ECG Setup Menu, Other Setup.
To conduct the 12-lead ECG monitoring, you can set PACE LEAD as I, II, III, aVR,
aVL, V1, V2, V3, V4, V5 and V6.
NOTE
z You can switch the leads by setting LEAD TYPE in the ECG SETUP
menu. At the time of switching between 12 LEADS, 5 LEADS and 3
LEADS, PACE LEAD in the ECG SETUP menu will be II.
z When you select the 12-lead analysis screen, the rhythm lead waveform
and the selected PACE lead waveform will be marked with PACE
indicator, but other lead waveforms will not be marked with the PACE
indicator.
The 12-lead ECG monitoring functions and other sub-menus are elaborated in the
following sections.
Entering the 12-lead ECG monitoring screen
In ECG SETUP menu, set LEAD TYPE to 12 LEADS to enter the 12-lead
monitoring. Consequently, 12-LEAD ANALYSIS and 12-LEAD REVIEW buttons
below the LEAD TYPE will be enabled.
12-lead analysis
In ECG SETUP menu, select 12-LEAD ANALYSIS to enter 12-lead analysis screen,
as shown in Figure 11-24.
The 12-lead analysis screen is also divided into the waveform area and parameter
area. In the parameter area on the right of the screen, the monitor displays 5
parameters: ECG, SPO2, NIBP, RESP and TEMP. In the waveform area on the left
of the screen, the monitor displays all waveforms (namely, 12 ECG waveforms and
a rhythm waveform) as default.
