IBP Monitoring
15-6
OFF: When a IBP alarm occurs, the monitor neither gives
alarm indications nor stores the alarm;
When OFF is selected, the
icon is displayed on the right
of the IBP (1,2) label.
îš„ ALM LEV
Alarm level
Options: HIGH, MED and LOW.
îš„ AMP ADJUST
Amplitude adjustment
This option allows you to adjust the waveform amplitude.
Options : MANUAL and AUTO.
1. MANUAL: If MANUAL is selected, you can select an IBP channel manually
from the options, including ART, PA, CVP, RAP, LAP, ICP, P1 and P2, and
then adjust the IBP scale in the SCALE ADJUST >> menu.
2. AUTO: If AUTO is selected, the waveform labels of IBP channels become P1
and P2 and the IBP scale is adjusted by the system automatically.
îš„ SWEEP
Waveform speed
Options: 12.5 and 25.0 mm/s.
îš„ UNIT
Options: mmHg and kPa.
îš„ FILTER
This option allows you to select the filter method of the IBP
waveform. Three options are available:
NORMAL: 16Hz filtering;
SMOOTH: 8Hz filtering;
NO FILTER: Displays the original waveform.
The default is NO FILTER.
îš„ ALM LIMIT
SETUP >>
This option allows you to access the following menu,
whereby you can set the upper and lower alarm limits.
Figure 15-6 IBP Alarm Setup Menu
