6-2 Display & Cine Review

5. Rotate <Zoom> to change the magnification factor. Or enter mapping-mode and use two-finger

gesture to change the magnification factor.

6. Press <Zoom> again to exit magnification.

6.2.2 Pan Zoom

To use the function, use the knob on the control panel.

1. Rotate the <Zoom> knob to directly enter the pan zoom status. Or enter the touch screen mapping

mode, and zoom the image by pinching the two fingers on the touch screen. Image-in-image is

displayed.

2. Magnification factor adjustment: rotate the [Zoom] knob or pinch two fingers under mapping mode

to change the magnification factor. The image magnification factor value will display in real time in

the image parameter area. For example, indicates that the magnification factor is 1.3.

3. Shifting the image: roll the trackball or touch and translate the image.

4. Press <Zoom> to exit pan zoom.

6.2.3 iZoom (Full-screen Zooming)

Function: to magnify the image in full screen.

Procedures:

1. Press <F8> to zoom in the image; the zooming area includes image area, parameter area, image

banner, thumbnail area and so on.

2. Press <F8> again to zoom in the image area only. The image goes to full-screen.

3. Press <F8> again to exit.

6.3 Freeze/Unfreeze the Image

Press [Freeze] key on the control panel to freeze a scanning image. In freezing mode, the probe stops

transmitting acoustic power, and all images as well as the parameters are kept still.

Tip: after freezing an image, the system may enter cine review, measure, comment adding, or body

mark mode, which is dependent upon preset. (Setting path: [Setup][System][General]"Status

After Freeze")

Press <Freeze> in frozen mode to unfreeze the image, and the system continues image scanning.

6.3.1 Imaging Mode Switching When Frozen

Imaging mode switching in frozen mode follows the following principles:

 In splitting display B mode, press <Dual>/user-defined <Quad> to switch among the windows; press

the user-defined <Single> key to exit splitting display mode and enter the image of the currently

activated window in full screen.

 In frozen mode, the system supports imaging mode switching between the sub-modes (only for the

activated window). For example, if the frozen image is of B+C+PW mode, then the system supports

imaging mode switching between B+C+PW, B+C, B+PW and B by pressing <C> or <PW>.

 The imaging mode and parameters of an unfrozen image is the same as the corresponding one that

before frozen; but the display format is the same as the one before unfrozen.
