2-14 System Overview
2.9 Control Panel
No. Name Description
<1> /
Power button
Turn on/turn off the system.
AC (Alternating current). It turns on at AC supply.
Standby. It blinks in orange in standby status.
Hard disk indicator. It blinks when reading the disk.
<2> A.power
Press the button to switch from A.Power and Volume.
Rotate the button to adjust the acoustic power or volume.
<3>
Soft menu key
(1-6)
Press the button to enable or disable the corresponding functions on
the touch screen.
Rotate the button to adjust the parameter on the touch screen.
<4> P1
User defined key. Press the button to enable or disable the user-defined
function. E-ink Supported. Set by the user in the Preset.
<5> PW/Y
Press to enter or exit the PW mode. When the PW mode is enabled:
If the Mark is not displayed, then press to display the Mark line;
If the Mark is displayed, then press to enter PW mode.
Rotate to adjust PW/CW gain; while in 3D/4D mode, rotate the knob
to make the 3D image rotate around Y axis.
