System Overview 2-15
No. Name Description
<6> C/Z
Press to enter or exit Color mode
Rotate to adjust Color/Power gain; while in 3D/4D mode, rotate the
knob to make the 3D image rotates around Z axis.
<7> M/X
Press to enter or exit the M mode. When the M mode is enabled:
If the Mark is not displayed, then press to display the Mark line;
If the Mark is displayed, then press to enter M mode.
Rotate to adjust M gain; while in 3D/4D mode, rotate the knob to
make the 3D image rotate around X axis.
<8> CW
Press to enter or exit the CW mode. When the CW mode is enabled:
If the Mark is not displayed, then press to display the Mark line;
If the Mark is displayed, then press to enter PW mode.
<9> PD Press to enter or exit the Power mode.
<10>
B
Press to enter the B mode;
Rotate to adjust the B or 3D/4D gain.
<11>
3D
Press to enter or exit the 3D mode.
E-ink Supported. Set by the user in the Preset.
<12>
4D Press to enter or exit the 4D mode.
Rotate to adjust the slice position of the 3D/4D mode.
<13>
Dual
In non-dual split mode, press to enter the dual split mode.
In dual split mode, press to switch the active window.
<14>
Single
Press to enter the single window mode.
E-ink Supported. Set by the user in the Preset.
<15>
Quad
In non-dual split mode, press to enter the quad split mode.
In quad split mode, press to switch the active window.
E-ink Supported. Set by the user in the Preset.
<16>
Depth
Slide upward to increase the depth by 1 unit in real-time imaging until
reaching the threshold.
Slide downward to decrease the depth by 1 unit in real-time imaging until
reaching the threshold.
<17>
Zoom
Rotate clockwise to zoom in the image; rotate anticlockwise to zoom
out the image.
Press to enter the spot-zoom mode, press again to enter pan-zoom
mode, and press for the third time to exit the zoom mode.
<18>
iTouch
Press to optimize the images, and keep pressing to further optimize
the image.
Long press to exit iTouch.
