2-2 System Overview
2.3.2 Environmental Conditions
2.3.3 External Dimensions and Weight
Item Specification Remark
External
Dimensions
Length: 1020±20mm;
Width: 550±10mm;
Height: 1000±20mm.
The monitor and the control panel are kept to a
minimum position
Weight 105kg ± 4kg Standard configuration without probes
2.4 System Configuration
2.4.1 Standard Configuration
Main unit
System software
Hard disk drive (HDD)
Solid state disk (SSD)
Accessories
Ultrasound gel
Dust-proof cover
Storage bin
Cable hook
Probe holders
Leakage-proof cap for the ultrasound gel
Cables
Dust-proof cover for the probe socket
Small keyboard
Operators manual
2.4.2 Probes and Needle-guided Brackets Available
For details about the probes and needle-guided brackets, please refer to "13 Probes and Biopsy".
Operational Conditions Storage and Transportation Conditions
Ambient
temperature
0°C-40°C
-20°C-55°C
Relative
humidity
20%-85% (no condensation) 20%-95% (no condensation)
Atmospheric
pressure
700 hPa-1060 hPa 700 hPa-1060 hPa
WARNING:
Do not use this system in the conditions other than those specified.
