Display & Cine Review 6-5
Cine review operations are the same as these of 2D mode.
Tips: There is no audio when the spectrum is reviewed in manual status but audio synchronization can
be realized in auto review status with speed of ×1.
6.4.4 Linked Cine Review
The linked cine review refers to review of the images captured at the same moment.
B/Color/Power/TVI/TEI dual live
B/B dual live
B+M synchronization mode
B+PW/TVD duplex mode
TVM, CM triplex mode
The frame mark on the time mark of M/PW image indicates the corresponding 2D image and M/PW
image. In statuses other than dual live status, you can only review images in the currently active
window.
6.5 Image Compare
6.5.1 Image Compare in Review Mode
1. Tap [Compare] on iStation screen (press <F2 iStation>) or Review screen (tap [Review]).
2. Select the images for comparison.
Click to select the image, and the icon appears on the right side of the image, which indicates
the image is to be compared.
If select the wrong image, click the image again to cancel the selection.
Select image size display on Thumbnail Sizebar to display more images at a time.
Tip: for B/B+COLOR/B+TVI/B+POWER/B+TEI mode image, you can select at most 4 images; for
PW/M/CW/TVD mode image, you can select at most 2 images.
Image compare of different exams for the same patient:
Time played
Total time
Start mark
Playback mark
End mark
Auto Review Region
Playback progress bar
Frame synchronization mark
