2-16 System Overview
No. Name Description
<19> Save
E-ink Supported. Set by the user in the Preset.
Supports 3 kinds of save mode:
1. Save single-frame image.
2. Save multi-frame image;
3. Select save mode based on different situations:
a) Real time: Auto cine replay: save multi-frame image
b) Freeze: save single-frame image.
<20>
Freeze
Press to freeze/defreeze the image.
<21> Print
Press to print the image.
E-ink Supported. Set by the user in the Preset.
<22> Angle
Rotate to adjust the angle.
Press to switch to the maximum steer angle.
<23> Bodymark Press to enter or exit Bodymark status.
<24> ABC Press to enter or exit Comment status.
<25> Clear
 Press to clear in the sequence of “the selected measurement and
comment information”, “screen information of the current application
mode”, and then “all measurement and comment information”
 Long press to clear all the measurement and comment information
on the screen.
<26> Cursor Press to display/hide the cursor.
<27> / Set key. The function is determined based on the actual situation. For
example, next one or previous one; or special command of some special
modes.
<28> /
<29> Measure
Press to enter/exit the application measurement mode, and start default
measurement.
<30> Caliper
Press to enter/exit the general measurement mode, and start default
measurement.
<31> Update
 Switch the current active window in multi-windows mode.
 Complete the image acquisition in iScape View/3D/4D mode etc..
<32> /
 Move the trackball to change the cursor position or repaly multi-
frame image.
 Adjust or move the VOI.
 Move the comment or body mark.
 Adjust the probe orientation of the body mark
<33> /
Battery indicator: displays the battery indicator
NOTE: Available only after the battery assembly is configured.
Tip: “/” means the key / knob has no silk-printed name.
