2-10 System Overview
No. Name Function
7. Touch control handle
Holding the right part of the handle to display the battery
indicator on the control panel.
NOTE: Available only after the battery assembly is
configured.
8.
lever
Used for lifting or swiveling the control panel.
9. Central brake
Used for locking the 3 full-lock casters.
NOTE: Available only after the central brake is configured.
10. Caster
With central brake:
Press the central brake pedal (used for locking the 3 full-
lock casters): press the red pedal of the double-lock
caster to lock the system.
Release the central brake pedal (used for locking the 3
full-lock casters): press the off pedal of the double-lock
caster to freely move the system; press the green pedal
of the double-lock caster to move the system straight.
Without central brake:
3 full-lock casters: press the “ON” pedal to lock the
system, and press the “OFF” pedal to move the system.
1 double-lock caster: press the red pedal to lock the
system, press the green pedal to move the system
straight, and press the “OFF” pedal to reset the green
and red pedals.
11. Probe port Sockets connecting transducers and the main unit.
12. Front I/O panel
Connecting to ECG leads, CW, USB drive, audio input and
output etc.
13. Speaker Outputs the audio.
14.
Intracavitary probe
holder
Used for placing the intracavitary probe.
15. Placing table
Used for placing the B/W video printer, storage bin, and wipes
box bracket.
To Next Page
