13-54 Probes and Biopsy
NOTE: refer to manufacturer manual for details about installation and disinfection of the magnetic
navigator. Contact the magnetic navigator if necessary.
To order needle sensor and needle sensor support, contact:
CIVCO Medical Instruments Co.
102 First Street South, Kalona, IA 52247-9589 USA Tel : 1-319-656-4447
E-mail: info@civco.com
http://www.civco.com
1. Refer to “5.17.2 Magnetic Navigator” for installation of magnetic controller, auxiliary power line,
USB cable, magnetic generator and probe sensor. Abdomen sensor is necessary under Fusion
imaging mode.
2. Connect the needle sensor to the 3rd port on the magnetic controller.
3. Put on the sterile sheath onto the needle sensor.
4. Insert the sensor into the needle.
eTRAX needle
eTRAX needle sensor
Sterile sheath
Biopsy needle sensor port
