System Overview 2-19
No. Symbol Description
Reserved, used for separate video output
14.
AUDIO
Audio input and output
15. HDMI High definition multimedia interface
16.
Microphone input jack
17.
When the probe locking lever points to , you can remove
the probe.
18.
- When the probe locking level points to , it means that
the probe is locked and you can not remove the probe.
- Central brake locking symbol
19.
Product serial number
20.
Manufacture date
21.
Manufacturer
22.
Temperature limit
23.
Humidity limitation
24.
Atmospheric pressure limitation
25.
Standby
26.
Direction of the probe cable
27.
Battery status indicator
28.
Positive inside and negative outside
29.
Unique Device Identifier
30.
CONFORMS TO AAMI STD ES 60601-1, IEC STD 60601-1-
6, 60601-2-37
CERTIFIED TO CSA STD C22.2 NO. 60601-1, NO. 60601-
1-6, NO. 60601-2-37
