System Preparation 3-9
3.5.2 Disconnecting a Probe
Perform the following procedure:
1. Toggle the locking lever to the right side.
2. Pull the transducer connector straight out vertically.
3.5.3 Probe Adapter Installation
Probe adapter is an option.
The following probes can be connected to the ultrasound system through probe adapter installation.
Probe Adapter Probe
PCM-ES01
SD8-1E
P7-3TE
SC6-1E
SP5-1E
PCM-US01
P7-3TU
SP5-1U
 Probe Adapter Illustration
Toggle the locking
lever to the left side
Toggle the locking
lever to the right side.
