4-9 / Positioning
(probe) sensor port
Motion (abdomen)
sensor port
2. Positioning (probe) navigation support: fix the support to
the probe. See the method below:
• The plastic markers on the probe (1 in the figure) and
on the positioning (probe) navigation support (2 in
the figure) must be on the same side.
• The silk prints on the probe (1 in the figure) and the
navigation support (2 in the figure) must be on the
same side.
• Push the navigation support fastened following the
arrow’s guide and lock it in the position shown in
Figure 1
No. Device
Name
Port Description
1
2
1
2
1
