6 - 46 Operator’s Manual
6 Image Acquisition
No. Device
Name
Port Description
1 Auxiliary
output
power
supply
cable
Power supply port Plug the auxiliary output power supply cable to the port of
the magnetic navigator, and connect the power supply.
NOTE:
Please use the auxiliary output power supply cable
equipped with the Ultrasound System.
2USB data
cable
USB port Plug one end of the USB data cable to the USB port of the
magnetic navigator, and another end to the USB port of the
Ultrasound System.
3 Magnetic
generator
Transmitter port Plug the magnetic generator to the Transmitter port. Place it
around the patient’s shoulder or two sides of the patient’s
abdomen. The magnetic generator should be frontal-faced
with the lesion. The frontal face of the magnetic generator
keeps 15-60 cm from the target within the scope 30 cm up/
down and towards probe.
NOTE:
Keep the magnetic generator away from the metal
devices or electromagnetic interference.
4-9 / Positioning
(probe) sensor port
Motion (abdomen)
sensor port
1. Plug two sensors to positioning (probe) sensor port
, and motion (abdomen) sensor port
respectively.
To Next Page
