Operator’s Manual 4 - 1
4 Setup
The Setup function is designed to set the configuration parameters of operating the system and
maintaining user workflow setup data. The setup data of the user and system are stored to the hard
drive, and should be backed up to CD/DVD or USB memory device.
When the preset data is changed, be sure to save the preset data according to
the methods described in this chapter. Mindray is not responsible for the loss of
preset data.
• To enter Setup:
Press <F10 Setup> on the keyboard to enter the setup menu.
• To exit Setup:
– Select [Save] in the Setup menu. The parameter settings are saved.
– Select [Cancel] in the Setup menu or press <ESC> to close the Setup menu.
When you change the system language and click [OK] in the Setup menu, the system
automatically shuts down to make the modification effective.
• Basic operations
The commonly-used setting types are:
– Text box: position the cursor over the corresponding field box. Enter the desired value
using the keyboard or soft keyboard on the soft menu.
– Radio button: click the button to select an item.
– Check box: click the checkbox to select one or more options.
– Drop-down list: click the arrow beside the list to select an item.
4.1 System Preset
The system automatically enters the [System] screen after you enter Setup.
Item Description
Region To set the hospital name, language, time zone, time format and system
date/time.
General To set patient information, exam setup, patient management, storage,
system dormancy, display and so on.
Image To set general parameters in imaging modes.
Application To set the measurement ruler, measurement setting, follicle method,
comment setting and so on.
OB To set the relevant information regarding the fetal gestational age, fetal
growth formula and fetal weight.
