Service Manual 0070-10-0556-02 3 - 7
Isometric Drawings and Part List Front Housing Assembly
FIGURE 3-3 Front Housing Assembly
LCD TFT DISPLAY 12.1"
Dress keypad Gnd Tail As Shown with
Conductive Side Facing PBC and so as not to
Interfere with Mounting Screws
24
11
10 15
12
4
2
23
