Front Housing Assembly Isometric Drawings and Part List
3 - 8 0070-10-0556-02 Spectrum
®
/Spectrum OR
™
Service Manual
ITEM NO DESCRIPTION PART NUMBER
1 Front Housing 0380-00-0387-01
1 Front Housing (Spectrum
®
/Spectrum OR
™
) 0380-00-0387-02
2 Cable Assembly Speaker 0012-00-0257-06
3 Holder Speaker 0380-00-0352
4 Encoder Optical 32 Position Push button 0311-00-0132
5 Main Keypad 0331-00-0120-01
6 Display TFT Color LCD 12.1 0160-00-0073-01*
6a Display TFT Color LCD 12.1 0160-00-0094*
7 PCB Assembly Display/Keypad 0670-00-0735
8 Bracket Mounting Inverter 0406-00-0821
8a Inverter Mounting Bracket 0406-00-0867
9 Inverter Board (OEM) 0671-00-0232
9a Inverter Board (OEM) 0671-00-0065
10 Cable Assembly Inverter 0012-00-1434
11 Cable Assembly 12.1 TFT Color LCD to Drive PCB 0012-00-1433
12 Cable Assembly Flexible Jumper 0012-00-1443-03
13 Gasket 12.1 Display 0348-00-0201
14 Foot 0348-00-0190
15 Label, Part Number Serial Number N/A
17 Screw Pan Head Cross Recessed #4-40 X 1/4 0212-12-0404
18 Washer, Flat Large Pattern 0210-10-0004
19 Standoff Hex Male/Female #4-40 X 5/8 Long 0361-30-0625
20 Screw, Pan Head Cross Recessed #4-40 X 3/8 0212-12-0406
21 Screw, 100° Flat Head Cross Recessed 4#-40 X 1/4 0212-17-0404
22 Screw, Pan Head Cross Recessed #2-56 X 3/16 0212-12-0203
23 Clamp Cable 1/8 Dia. Self-Adhering 0343-00-0108
24 Grommet Edging 0348-11-0003
25 Ferrite Flat Cable Split 0108-00-0097-01
26 Clip Flat Ferrite 0344-00-0248-02
27 Cable Tie 0125-01-0003
28 Cushion Ferrite 0348-00-0211
* Must order a gasket (0348-00-0201) item 13 for each display replacement.
