Spectrum
®
/Spectrum OR
™
Service Manual 0070-10-0556-02 3 - 23
Isometric Drawings and Part List Rear Housing Assembly
ITEM NO DESCRIPTION PART NUMBER
1 Rear Housing 0380-00-0339-04
2 Foot 0348-00-0190
3 Handle 0367-00-0061
4 Pin Handle 0226-00-0017
5 PCB Assembly, Module Interface 0670-00-1155-01
6 Bracket Recorder Mounting (AR-42) 0406-00-0741
7 PCB Assembly, Recorder Interface 0670-00-0695
9 Label, Part Number/Serial Number N/A
10 Fan Assembly w/Cable 9.89 CFM 0012-00-1622-01
10a Screw, Pan Head Cross Recessed #6-32 x 9/16 0012-12-0609
11 Plate Ground 0386-00-0290
12 PC Board Assembly Main/CPU TFT
(Use with S/N MM XXXX-XX)
0670-00-0782-02
12a PC Board Assembly Main/CPU TFT
(Use with S/N MS XXXX-J5 or above)
0670-00-0782-01
13 Cable Main Board to Interconnect Board 0012-00-1210
14 Cable Assembly Power Switch 0012-00-1231
15 PCB Assembly, NIBP module 0670-00-0746-01
15 NIBP Module Assembly 0670-00-0798-01
16 Cable Assembly Pump NIBP 0012-00-1249
17 Bracket Pump 0406-00-0750
18 Cable NIBP to Main Board 0012-00-1211
19 Cover Power Supply 0198-00-0051
20 Door Battery Access 0380-00-0349
21 Strap Grounding Plastic Battery Holder 0346-00-0049
22 Cover Transceiver 0198-00-0027
23 Screw, Pan Head Cross Recessed #6-32 x 5/16 0212-12-0605
24 Screw, Pan Head Cross Recessed #6-32 x 7/16 0212-12-0607
25 Screw, Pan Head Cross Recessed #4-40 x 3/8 0212-12-0406
26 Screw, Pan Head Cross Recessed #4-40 x 3/4 0212-12-0412
27 Screw, Pan Head Cross Recessed #4-40 x 7/16 0212-12-0407
28 Screw, Pan Head Cross Recessed #6-32 x 3/16 0212-12-0603
29 Screw, Pan Head Cross Recessed #4-40 x 1/2 0212-12-0408
30 SpO
2
Board Assembly Nellcor
®
304P 0671-00-0162
30a SpO
2
Board Assembly Nellcor
®
OxiMax 0671-00-0066
31 PCB Assembly Nellcor Interface 0670-00-0696
31a PCB Assembly Masimo/Nellcor Interface Bd
(use with CPU Bd 0670-00-0782-XX only)
0670-00-0785-XX
32 Cable, Nellcor SpO
2
Interface Bd to Main Bd 0012-00-1233
33 Cable Assembly, Nellcor SpO
2
0012-00-1356
33a Cable Assembly, Nellcor SpO
2
OxiMax 0012-00-1634
34 SpO
2
Board Assembly Masimo
®
MS-3 0671-00-0055
35 Cable, Masimo SpO
2
to Main Board 0012-00-1201
36 Spacer Nylon Richco 0361-45-0403
