Rear Housing Assembly Isometric Drawings and Part List
3 - 24 0070-10-0556-02 Spectrum
®
/Spectrum OR
™
Service Manual
37 Cable Assembly, Masimo SpO
2
with Choke 0012-00-1308
38 Battery Holder Assembly, Plastic, Sealed Lead Acid 0997-00-0972-01
38 Battery Holder Assembly, Plastic, Lithium-Ion 0997-00-0972-02
39 Power Supply/Charger (Sealed Lead Acid) 0014-00-0250
39 Power Supply/Charger (Lithium-Ion) 0014-00-0251
40 Screw, Pan Head Cross Recessed #4.40 x 3/16 0212-12-0403
41 CO
2
Input Assembly 0012-00-1400
42 Screw, Pan Head, Nylon #4.40 x 1/4 0212-01-0404
43 Strap, Battery Door 0346-00-0047
44 Insulator, Nellcor SpO
2
, Interface Board 0349-00-0322
45 Screw, Pan Head Cross Recessed #6.32 x 1 1/4 0212-12-0620
46 Screw, Pan Head Cross Recessed #6.32 x 5/8 0212-12-0610
47 Screw, Pan Head Cross Recessed #4.40 x 1/4 0212-12-0404
48 Screw, Metric Flat Head 0211-00-0140
49 Recorder Thermal Array (AR-42 Special) 0683-00-0465-01
50 Recorder Plate, Blank 0370-00-0017-03
51 MediCO
2
Module Assembly (Oridion)
miniMediCO
2
Module Assembly (Oridion)
0671-00-0164-03
0671-00-0089-01
52 Cable CO
2
to Main Board (MediCO
2
) 0012-00-1200
52 Cable CO
2
to Main Board (miniMediCO
2
) 0012-00-1683-01
53 Retainer CO
2
Connector 0226-00-0018
54 Standoff Hex Male/Female #6.32 x 0.250 long 0361-27-0250
55 Connector Panel Masimo w/CO
2
0380-00-0348-01
55 Connector Panel Masimo w/o CO
2
0380-00-0348-02
55 Connector Panel Nellcor w/CO
2
0380-00-0348-03
55 Connector Panel Nellcor w/o CO
2
0380-00-0348-04
55 Connector Panel Nellcor Oximax w/ CO
2
0380-00-0348-05
55 Connector Panel Nellcor Oximax w/o CO
2
0380-00-0348-06
56 Tape Double-sided 5/8 wide 0215-00-0115
57 Bracket CO
2
Mounting Thru-Hole End (MediCO
2
) 0406-00-0783
57 Bracket CO
2
Mounting Upper (miniMediCO
2
) 0406-00-0879
58 Bracket CO
2
Mounting Slotted End (MediCO
2
) 0406-00-0805
58 Bracket CO
2
Mounting Lower (miniMediCO
2
) 0406-00-0885
59 Screw, Pan Head Cross Recessed #6.32 x 1/4 0212-12-0604
60 Screw, Pan Head Cross Recessed #6.32 x 3/8 0212-12-0606
61 Clamp Cable 3/16 Self Adhesive 0343-00-0007
62 Washer, Flat 0.470 OD, 0.119 ID 0221-00-1014
63 PC Board Assembly Patient Connector AAMI w/IBP 0670-00-0682-01
63 PC Board Assembly Patient Connector AAMI w/o IBP 0670-00-0682-02
63 PC Board Assembly Patient Connector HP 0670-00-0680-01
64 Cable Panel to Main Board 0012-00-1206-01
65 Screw, Pan Head Cross Recessed #4.40 x 5/16 0212-12-0405
66 Pneumatic Fitting Male Panel Mount 0103-00-0489
ITEM NO DESCRIPTION PART NUMBER
