Comm-Port Isometric Drawings and Part List
3 - 30 0070-10-0556-02 Spectrum
®
/Spectrum OR
™
Service Manual
ITEM NO DESCRIPTION PART NUMBER
1 Housing, Top, Comm-Port 0380-00-0346
2 Screw, Pan Head, #4-40 X 5/16 0212-12-0405
3 Screw, Captive, Pan Head, Cross Recessed 0217-02-0004
4 Socket, Guide, Docking Connector 0132-00-0077
5 Label, Information, Comm-Port 0334-00-1533
6 Label N/A
7 PCB Assembly, Comm-Port, CS1/MB1/RD1 0670-00-0690
8 Housing, Bottom, Comm-Port, -03 and -04 0380-00-0347-03
9 Label, "CS1, MB1, RD1", Comm-Port 0334-00-1536
10 PCB Assembly, Comm-Port, RD1/NC1/SP1 0670-00-0692
11 Housing, Bottom, Comm-Port, -05 and -06 0380-00-0347-04
12 Label, "RD1, NC1, SP1", Comm-Port 0334-00-1573
13 PCB Assembly, Comm-Port, SP1/NC1/SP2 0670-00-1140
14 Label, "SP1, NC1, SP2", Comm-Port 0334-00-2521
15 Label, "CS1, MB1, SP1", Comm-Port 0334-00-1541
16 PCB Assembly, Comm-Port, CS1/MB1/SP1 0670-00-0684-01
