— 1.19
Calibration without weight
SM)
— 1.19.1 Maximum capacity
— 1.19.3 Sensitivity 1
— 1.19.4 Sensitivity 2
— 1.19.5 Sensitivity 3
— 1.19.6 Sensitivity 4
— 1.19.7 Zero point/dead load
— 1.19.8 Save parameters
Note:
The entered data is saved by selecting the menu item 1.19.8. Once it has been saved, the
data can no longer be read out.
Menu tree for calibration without weight
Menu: [SETUP]- [WP-1]- [INTERN]- [1.19] (see also Chapter 6.3.1.1).
SM)
only visible in service mode
Procedure
If the weighing platform consists of several load cells, multiply the maximum capacity
accordingly (e.g. four load cells of 50 kg each result in a maximum capacity of 200 kg)
For weighing platforms with multiple load cells: Enter the individual values for each of
the load cells (menu items 1.19.3 … 1.19.6 or enter the average value across all cells
(menu item 1.19.3)
1. Open the locking switch (see Chapter ).
2. Activate service mode (see Chapter 5.5.2).
3. Select the weighing platform.
4. Enter the maximum capacity of the load cell(s) in kg (menu item 1.19.1).
5. Enter the sensitivity of the load cell in mV/V (menu item 1.19.3).
6. Enter the dead load of a silo construction in mV/V (menu item 1.19.7).
7. Save values for calibration without weight (menu item 1.19.8).
8. Close the locking switch.
