Minebea Intec Ex Indicator Midrics 1 - Output Format with 16 Characters (Without Header)

that the print line consists of 16 characters (14 printable characters plus two control
characters).
Example: Output without marking
+ 253 pcs 16 characters are displayed
Example: Output with marking
Qnt + 253 pcs 22 characters are displayed
Characters that are not visible in the display are displayed as blank spaces. No decimal
point is displayed for numbers without a decimal point.
8.5.1 Output format with 16 characters (without header)
Normal operation
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ * A A A A A A A A * E E E CR LF
or – * A A A A A A A A * E E E CR LF
or * * * * * * * * * * * * * CR LF
+ -: Algebraic sign
*: Blank space
A: Characters of the display (max. 7 characters and decimal point)
E: Characters for the unit (1 … 3 letters, followed by 2 … 0 blank spaces)
CR: Carriage Return
LF: Line Feed
Special operation
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
* * * * * * * – – * * * * * CR LF
or * * * * * * * H * * * * * * CR LF
or * * * * * * * H H * * * * * CR LF
or * * * * * * * L * * * * * * CR LF
or * * * * * * * L L * * * * * CR LF
or * * * * * * * C * * * * * * CR LF
*: Blank space
– –: Output weight
H: Overload
HH: Checkweigher overload
L: Underload
LL: Checkweigher underload
C: Calibration
