Error message
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
* * * E r r * * # # * * * * CR LF
or * * * E r r * * # # # * * * CR LF
*: Blank space
#: Number (2‑ or 3‑gure error number)
Example:
Output of the weight value +1255.7 g
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ * * * 1 2 5 5 . 7 * g * * CR LF
Position 1: Algebraic sign +, - or blank space
Position 2: Blank space
Position 3 … 10: Weight value with decimal point. Leading zeros are displayed as blank
spaces.
Position 11: Blank space
Position 12 … 14: Character for measurement unit, blank space or character ! as symbol
Position 15: Carriage Return
Position 16: Line Feed
8.5.2 Output format with 22 characters
Normal operation
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
K K K K K K + A A A A A A A A A * E E E CR LF
or K K K K K K – A A A A A A A A A * E E E CR LF
or * * * * * * * * * * * * * * * * * * * * CR LF
K: Character for marking, right-aligned lled with blank spaces
+ –: Algebraic sign
*: Blank space
A: Characters of the display (max. 7 characters and decimal point)
E: Characters for the measurement unit (1 … 3 letters, followed by 2 … 0 blank spaces)
CR: Carriage Return
LF: Line Feed
Special operation
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
S t a t * * * * * * * * * - - - * * * * CR LF
or S t a t * * * * * * * * * H * * * * * * CR LF
or S t a t * * * * * * * * * H H * * * * * CR LF
or S t a t * * * * * * * * * L * * * * * * CR LF
