Congure Midrics 1 (MIXS1) on the COM1 interface according to the parameters of the
main scale or indicator, e.g.: [SETUP]- [WP-1]- [COM-1]- [RS-232]- [XBPI.232] (ADC-232)
or [SETUP]- [WP-1]- [COM-1]- [RS-2323]- [SBI-STD] (SBI-APP).
8.7 Congure data interface as printer interface (PRINTER)
One printer can be connected to MIXS1. Printouts are triggered at the touch of a button or
automatically. In addition, the current menu settings can also be printed out.
The interface COM1 is congured as a printer interface under [PRINTER].
A command for the data output to the printer interface is generated:
- when requested via the key .
If the user is in the operating menu, then all menu settings under the currently
displayed menu item are printed out.
In normal weighing mode, the weight value is printed out according to the protocol
conguration.
- After receiving the SBI command "ESC k P _", a print protocol is output if COM1 is set
as the data interface and SBI is set as the protocol printout.
For this purpose, see the section "Data input format" in this Chapter (8.4).
During the data output, the symbols and are shown in the display.
8.8 Conguring print output
The printout is congured under "Print protocols" in the [SETUP]- [PRTPROT] Setup
menu. Each protocol is composed of dierent information blocks which are activated or
deactivated by multiple selection in the menu.
Headers
2 headers with max. 20 characters each are available (e.g.for printing the company
name).
The headers are entered under menu items 7.4.1 and 7.4.2.
Example print image:
EISENSCHMIDT
Bovenden
In this example, the company name is printed in the center because the text is preceded
by 4 or 5 blank spaces.
Date/time
Example print image:
12.08.2021 16:02
In order to maintain a uniform time (e.g. for documentation within a complete automation
system), the imprint of the time in the "Date/time" block can be omitted. Factory setting:
"Print time" (menu item 7.14.2).
If "Do not print time" is set (menu item 7.14.1), the time can be inserted, e.g. by a higher-
level controller, in order to always have the same time in the system. This setting is
particularly suitable for communication with a PC.
