Minebea Intec Ex Indicator Midrics 1 - Automatic Data Output (SBI); Alibi Memory; Secondary Display

Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
or S t a t * * * * * * * * * L L * * * * * CR LF
or S t a t * * * * * * * * * C * * * * * * CR LF
*: Blank space
– –: Output weight
H: Overload
HH: Checkweigher overload
L: Underload
LL: Checkweigher underload
C: Calibration
8.6 Automatic data output (SBI)
The measurement result can be released automatically
1)
. This can take place depending
on a number of display cycles
2)
and may be linked to the standstill of the scale
3)
. The
display interval depends on the operating status of the scale and the scale type.
Examples:
N + 153.00 g
Stat
Stat L
Stat H
Net weight
Display dark
Display underload
Display overload
"Data output" setting:
1) 3)
"Automatic, without standstill" or "Automatic, with standstill".
Factory pre-setting: Manual data output after standstill, i.e. automatic data output
switched o.
2)
Automatic data output time-dependent: Time dependence: 1, 2, 10 or 100 display cycles
Factory setting: 1 display cycle
8.6.1 Alibi memory
There is an internal Alibi memory built in by default that can store up to 523,700 records.
If a printer is congured for the COM-1 interface in the menu, it is written to the Alibi
memory each time the key is pressed.
For more detailed information on the Alibi memory, refer to the description of option E5.
8.6.2 Secondary display
The Midrics 1 (MIXS1) can be used as a secondary or remote display for another Minebea
Intec explosion-protected scale or indicator. To do this, congure the following:
On the scale/indicator
Set an interface on XBPI-232, e.g. [SETUP]- [COM1]- [DATPROT]- [XBPI-232] or SBI, e.g.:
[SETUP]- [COM1]- [DATPROT]- [SBI]- [5.1.7]- [6.1.5].
On the secondary display
