9. Fieldbus interface | 9.2 - Scale protocol | 122

9.2.5.9 Function number 8–11, 14: weight data (read)

The gross, net, and tare weight are stored as a DINT fix point. The real data

value is derived from DINT and EXPO as follows:

Value

Real

= reading

DINT

× 10

(-EXPO)

Function number 8 Current gross value

Function number 9 Current net value, if tared; otherwise gross

Function number 10 Current tare value, if tared; otherwise 0

Function number 11 Current gross/net weight selected with bit 72.

Function number 14 max. capacity (Max)

9.2.5.10 Function number 24–29: Limit value (Read/Write)

Function number 24 Limit 1 on

Function number 25 Limit 1 off

Function number 26 Limit 2 on

Function number 27 Limit 2 off

Function number 28 Limit 3 on

Function number 29 Limit 3 off

9.2.5.11 Function number 30, 31: Fixed values (Read/Write)

Function number 30 Fixed value for analog output, value (num) 0

20000 corresponds to 20mA

Function number 31 Fixed value for preset tare, see also SetFixTare, Get

FixTare in ChapterData exchange range.
