9. Fieldbus interface | 9.2 - Scale protocol | 123
9.2.5.12 Function number 80–89: state-controlled action bits (write)
Note:
For setting bits, see ChapterWriting bits .
Only setting and resetting of single bits is possible.
When changing a bit from 0 to 1, the corresponding action starts. After han
dling the command, the bit must be reset. Application: The master writes
cyclically.
The bit is set as Write_Value_Select with the specified number (see Chapter
Writing bits ).
The bit is reset at the specified number +128.
Function number 80 SetZero Set the gross weight to zero.
Function number 81 SetTare The weighing point is tared.
Function number 82 ResetTare Reset tare.
Function number 83 SetTest Start the ADC test.
Function number 84 ResetTest Finish the ADC test.
Function number 85 ResetPwf Reset the PowerFail bit (function
number1; the bit was set after
"power on").
Function number 86 SetFixTare Taring with weight in numerical
address D31 "FixTare".
Function number 87 GetFixTare The current gross weight is copied
to the numerical address D31.
Function number 89 ResetError The CmdError error bit is reset.
