Minebea Intec Signum 3 Ex User Manual

114
Signum 3 Ex
Control Drawing Control Drawing
Sheet of
2013-12-12
Dr. D. Klausgrete
SIWXS…-3-..-…, SIWXS…-3-V…,
ISX…-..-…, ISX…-V…
Power
2)
13)9)
3)
Hazardous (Classified) Location
Class I, II, III, Division 1, Groups A,B,C,D,E,F,G
Class I, Zone 1, Groups IIA, IIB, IIC
Zone 21
SARTORIUS
Weighing Unit
Series
SIWXS…-3-..-…,
SIWXS…-3-V…,
ISX…-..-… and
ISX…-V…
WARNING:
SIWXSBBP-3-06-H.. ,
ISXBBP-06-H.. and all ...-V1..
models may not be used in
Class II, III, Groups E,F,G
and in Zone 21, respectively!
Data
2)
6)
3)
3)
SARTORIUS
Power Supply Type
YPS02-XUR
19)
YPS02-XKR
18)
Non-Hazardous Location
Hazardous (Classified) Location
Class I,II,III, Division 1,
Groups A,B,C,D,E,F,G
Canada: Group A is excluded!
Power
2)
3)
SARTORIUS
Power Supply Type
YPS02-XKR
16)
Hazardous (Classified) Location
Class I,II,III, Division 2,
Groups A,B,C,D,E,F,G
Class I, Zone 1, Groups IIA, IIB
Class II, Zone 21
SARTORIUS
Rechargeable
Battery Pack
YRB02-X
17)
5)
Data Interface Board
8)
10)
T-Connector
11)
10) or 12)
Any NRTL approved
equipment with Entity
Concept parameters
E.g. SARTORIUS
Interface Converter Type
YDI05-Z
15)
7)
Display Unit of the
SIWXS...-3-..-...
3)
Any NRTL approved equipment with
Entity Concept parameters
E.g. SARTORIUS Indicator
CIXS3-.
14)
CAIXS2-....
20)
4)
4)
4)
9)
5)
5)
5)
: Alternative connection
13)
