Signum 3 Ex
Data Interface
Error Message:
Pos� 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
S t a t * * * * * E r r * * # # * * * * CR LF
or S t a t * * * * * E r r * # # # * * * * CR LF
*: Space
#: Error code number (2 or 3 digits)
ID Code Characters:
Character K Meaning
G# Gross value
N Net value
T Application tare memory 1
T2 Application tare memory 2
Diff Dierence from adjustment value
Targ. Exact adjustment weight value
Nom. Exact adjustment weight for SBI printout
nRef Reference sample quantity
pRef Reference percentage
wRef Reference piece weight
Qnt Result from Counting (piece count) and
NeutralMeasurement applications
mDef Target value for animal weighing
x-Net Animal weighing results
Setp Target value for checkweighing
Diff.W. Absolute deviation (e�g�, in kg) in Checkweighing
Lim Deviation in % in Checkweighing
Max Upper tolerance for checkw�
Min Lower tolerance for checkw�
Stat Status
Classx Classication
Limx Class limit
D Percentage (as loss)
Prc Percentage (as residue)
Wxx% Reference percentage weight
Cmpxxx Component xxx
Cont.T Contents of the tare memory
in Net-total Formulation
S-Comp Total of initial weighings
for Net-total Formulation
PT2 Preset tare
n Transaction counter
*G Sum of gross weights
in Totalizing
*N Sum of net weights
in Totalizing
Ser.no. Serial number of the platform or indicator
Example (output of weight value of +1255�7 g):
Pos� 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
G # * * * * + * * * 1 2 5 5 � 7 * g * * CR LF
Positions 1-6: ID code, right-justified with spaces
Position 7: Plus +, or minus - or space
Position 8: Space
Positions 9-16: Weight value with decimal point�
leading zeros are output as spaces�
Position 17: Space
Positions 18-20: Characters for unit of measure or space
Position 21: Carriage return
Position 22: Line feed
!
If the weight value is output with 10-fold increased resolution,
this value may not be printed or saved in a weighing instrument
operated in legal metrology in SBI operation�
In this case, the unit symbol is not included with output�
Conguring the Data Interface as a Printer Port
(printer,
when com1 is not RS485)
You can connect either a strip or label printer to Signum
®
using
abarrier like YDI05-Z (see proof of intrinsic safety, drawing
36953-750-60)� Congure the COM1 interface as a printer port
under the “Printer” menu item�
There are several actions that generate the command for outputting
data to the printer port:
– Pressing the pkey� If the operating menu is active, all menu
settings under the active menu level are printed�
– Upon receipt of the “Esc k P _” SBI command� For details, see the
section entitled “Data Input Format” in this chapter�
– In some applications, pressing a given key (e�g�, to save a value
or start a routine) also generates a print command� In this case,
acongurable printout is generated with application-specic data�
The P and b symbols are displayed when data is being output to
the printer port�
