Signum 3 Ex
Operating Concept
Error Messages
– If a key is inactive, “-------” and|or
“Nofunction” is displayed briefly
(2sec�)
– Temporary errors are displayed for
2seconds in the weight value/result
line via an error code (e�g�, Inf 09);
fatal errors (e�g�, Err 101) are displayed
continuously until “Reset" is used�
Error codes are described in detail under
“Error Codes”�
Data Output
Printer
You can connect a strip or label printer to
Signum
®
3� You can have printouts output
at the press of a key or automatically�
Printout formats are user-denable� You
can also congure separate summarized
printouts, and print a list of the active
menu settings� See section “Conguring
Printouts”�
Digital Input/Output Interface
+ Optional I/O
The digital input/output interface is
supported by the “Checkweighing" and
“Classification" application programs�
Checkweighing
The output device has a number of
control functions� Four data outputs
transfer signals for “less than,” “equal
to,” “greater” and “set�” You can define
whether the outputs are always active or
are activated only at stability, only within
the checkweighing range, only within
the checkweighing range at stability,
orswitched off�
Classification
Four data outputs transfer information on
the class of the load (Class 1, 2, 3, 4 or 5)
and indicate when the minimum load is
exceeded (Set)�
You can define whether the outputs are
always active, activated only at stability,
or off� See “Application: Classification” in
the enclosed “Basic Application Programs”
manual for details�
Communication Interface
You can define a number of parameters
for this SBI interface (print command,
time-dependent autoprint, ID codes)�
Seesection “Data Interface”�
Saving Data
Signum
®
3 saves all application parameters
(e�g� reference values) when the device
is turned o or you switch between
application programs� You can assign a
password to prevent unauthorized users
from changing settings in the “Device
parameters” menu under:
setup
u-code
see “Conguration”
Configuration
