Signum 3 Ex
Counting Application Z
Neutral Measurement Application Z nM
Neutral Measurement
Application Z nM
With this application you can use your
weighing platform to measure the
length, surface and volume of parts
that have roughly the same specic
weight� The o symbol is displayed
asthe weight unit�
Characteristics
– Save the reference weight “wRef” from
the weighing platform
– Enter the reference weight “wRef” using
the keypad
– Enter the calculation factor “nRef”
using the keypad
– Activate Info mode with the I key
– Toggle the display between
measurement and weight using the
wkey
– The level of accuracy (display
resolution) can be set when the
calculated reference weight is applied
– Automatic taring of container weight�
Configured in Setup under:
Appl: a.tare: 3.7.
– Automatic initialization when the
scale is switched on� The indicator is
initialized with the most recently used
calculation factor “nRef” and reference
weight “wRef�” Configured in Setup
under:
Appl: a.start: 3.8.
– Exit application, delete parameters:
The value of the reference sample
weight in the reference memory remains
active until it is deleted, overwritten or
the application is changed using the
ckey� The reference sample weight
also remains saved after the scale is
turned o�
You can assign dierent functions to
the c key for deleting applications�
When you clear applications, you can
delete either the data stored for all
applications or just selected data stored
for the active application� Congured in
Setup under:
Appl: sel.cf: 3.24.
(Sel� CF function key c in
applications)
– Tare function:
1) If you store a tare (weight value)
by pressing the ) key, you can later
enter a tare value manually� The tare
value you enter is added to the stored
tare value� Setting: menu code 3�25�1
(factory setting)
2) A tare value entered manually
overwrites a stored tare value (weight
value)� If you enter a tare value
manually, a tare value (weight value)
stored later overwrites the manually
entered value� Setting: Menu code
3�25�2
Congured in Setup under:
Appl
: tare. f: 3.25.
– Restore factory default settings�
Configured in Setup under:
Appl: def.app: 9.1.
In order to calculate the length, surface
or volume of a given sample, the
average weight of a reference quantity
of the sample must be known (in the
example below, the reference is 1 meter
of electrical cable)� There are three ways
to enter the reference weight in the
program:
– Calculation:
– Place the reference quantity (dened
by the calculation factor) on the
connected weighing platform and
calculate the reference sample weight
by pressing the O key
– Place any amount of the sample
material on the connected weighing
platform, enter the calculation factor
through the keypad, and press the
Okey to calculated reference sample
weight�
How the reference weight is calculated
depends on the application setting for
resolution� The value is either rounded
o in accordance with the display
resolution, or saved with 10-fold or 100-
fold resolution, or with the maximum
internal resolution of the weighing
platform�
– Enter the reference weight (i�e�, the
weight of one meter of electrical cable)
using the keypad and press
O to save
it�
The initial application values remain
active until deleted by pressing the
ckey or until overwritten by a new
value� They remain saved after the scale
is switched o�
Preparation
§ Turn scale on: Press the e key
§ While all segments are lit, press the
)key
§ Select Setup: Press the k key
repeatedly until appl is displayed
§ Conrm appl: Press the ) key
§ Select the Neutral Measurement
application:
Press the k key repeatedly and
conrm with the ) key
Neutral Measurement Application Parameters
3�6� Minimum load for initialization
3�6�1* 1 digit
3�6�2 2 digits
3�6�3 5 digits
3�6�4 10 digits
3�6�5 20 digits
3�6�6 50 digits
3�6�7 100 digits
3�6�8 200 digits
3�6�9 500 digits
3� 6�10 1000 digits
3�9� Reference value calculation
resolution
3�9�1* Display accuracy
3�9�2 Display accuracy
+ 1 decimal place
3�9�3 Display accuracy
+ 2 decimal places
3�9�4 Internal resolution
3�10� Decimal places in displayed result
3�10�1* None
3�10�2 1 decimal place
3�10�3 2 decimal places
3�10�4 3 decimal places
3�11� Parameter for saving weight values
3�11�1* With stability
3�11�2 With increased stability
* = Factory setting
§ Save the settings with the ) key and
exit Setup: Press the ( key several
times�
