Minebea Intec Signum 3 Ex - Common Specifications; Model Designator

88
Signum 3 ExSignum 3
Specifications
General Specifications
Digital protective interface according to EN45501
Data interface bidirectional RS-232C interface with control output (standard equipment)
Additional data interface optional
Display 14-segment backlit display
Weighing platform housing: Aluminum die-casting,
display unit stainless steel
Protection class according to EN60529 IP65 (SIWXSBBP-06*: IP43)
Temperature range –10°C to +40°C
+10°C to +30°C (SIWS���-�CE)
Power supply via AC adapter YPS02-Z�� or YPSC01-Z respectively (for installation outside of the hazardous area
only) or YPS02-X�� or YPSC01-X respectively (also for installation within the hazardous areas of the
zones 1 and 21)�
100–240 V AC (+/–10 %), 50–60 Hz
battery operation via external rechargeable battery YRB02-X
Interference emission acc� to EN61326+A1 Class B (IEC 61326+A1)
Defined immunity to interference acc� to EN61326+A1, industrial environment (IEC61326+A1)
Electrical safety acc� to EN61010-1 (IEC 1010-1), EN60950 (IEC 950)
Signum
®
Model Designator
Model type Sensor Platform Material/ Application Weighing Display Veriable/
technology dimensions design level capacity resolution veried
(kg) models
Example SIWXS: SIWXSDCP-3-16-H
SIWX S
3
) DC P
4
) -3 06 S
BB S
5
) 3 H
6
35
3
) = SIWXS: “Supreme,: monolithic weighing system
4
) = painted
5
) = stainless steel
Specifications
