Minebea Intec Signum 3 Ex User Manual

40
Signum 3 Ex
Preparation
§ Switch on the scale: Press the e key
§ While all segments are lit, press the
)key
§ Select Setup: Press the k key repeat-
edly until Setup is displayed
§ Open the Setup menu: Press the
)key
$ Select weighing platform 1 “WP1":
Pressthe ) key or
Setup
wp-1
1
1�9� Calibration and Adjustment
1�9�1 * Ext� calibration/adjustment; default weight
1�9�3 External calibration/adjustment; weight can be selected under menu item 1�18�1
1�9�4 Internal calibration/adjustment (models with built-in motorized calibration weight only)
1�9�8 Set preload
1�9�9 Clear preload
1�9�10 J key locked
1�10� Calibration/Adjustment sequence
1�10�1 Calibration with automatic adjustment
1�10�2 * Calibration with manual adjustment
1�11� Zeroing range
1�11�1 1 percent/max� cap�
1�11�2 * 2 percent/max� cap�
1�12� Initial zero point range
1�12�1 Factory setting (depending on the model type)
1�12�2 2 percent/max� cap�
1�12�3 * 5 percent/max� cap�
1�13� Tare/zero at power on:
1�13�1 * On
1�13�2 O, load previous tare values
1�13�3 Only zero at power on
1�16� External adjustment
1
)
1�16�1 * Activated
1�16�2
2
) Blocked
1�17� Adjustment weight unit
1�17�1 Gram
1�17�2 * Kilogram
1�17�3 Pound
1
)
1�18� Entering adjustment weight
1�18�1 External user adjustment weight (enter value, e�g�: 10,000g)
§ Save the settings with the ) key and exit Setup:
Press the ( key several times�
1
) Not available on scales veried for use in legal metrology
2
) = Factory setting for use in legal metrology
* Factory Settings
Operation Operation
