Map Screen
CTX 3030 Instruction Manual
Using the Map Button
Use the map button from any screen view the Map screen, cycle between zoom
levels and access the Map Quick Menu.
Press the Map button to cycle between zoom levels.
Press and hold the Map button to display the map menu and initiate the following
actions:
• Clear GeoTrail
• View GeoTrail
• Recenter
• Show Names
Clear GeoTrail
The Clear GeoTrail option will remove the current GeoTrail from the map screen.
View GeoTrail
The View GeoTrail option will display the current GeoTrail on the map screen.
Recenter
The Recenter option will place your current position at the center of the map
screen.
Show Names
The Show Names option will show or hide the names of all FindPoints and
WayPoints displayed on the map screen. By default the Show Names option is on,
but names can be hidden to save space when many items are displayed on the
screen at once.
Using the Store Button
Use the Store button to store FindPoints and WayPoints, and control a GeoHunt:
1. Press the Store button to create and store FindPoints and WayPoints
2. Press and hold the Store button to control a GeoHunt
Create and Store FindPoints and WayPoints
1. Press the Store button to display the FindPoint/WayPoint menu. The available
options are:
• Create FindPoint
• Create WayPoint
2. Use the arrow buttons to highlight Create FindPoint or Create WayPoint and press
Select to display the following:
• Name of item
• Option to Save
• FE-CO coordinates of item
• Lat-Long coordinates of item
Map
Store
NOTE
A valid GPS position x is required
to use the Store button functions.

Minelab CTX3030 Specifications

General

Operating Frequency	1.5 kHz - 100 kHz
Display	Full color LCD
GPS	Yes
Wireless Audio	Yes
Waterproof	Up to 3 meters
Weight	5.2 lbs (2.36 kg)
Search Modes	Beach, Coin, Relic
Sensitivity Levels	Adjustable
Coil Size	11-inch
Target ID	0-50 scale
