User Button
CTX 3030 Instruction Manual
User Button
ʯ Press to activate your
selected function
ʯ Press and hold to assign a
function to the user button
User Button
The purpose of the User button is to provide easy access to your favorite functions.
There are nine dierent functions that can be assigned to the User button, and
once a function has been assigned, it will be activated each time the button is
pressed. By default, pressing the User button will activate the Backlight.
The available User button functions are:
• Backlight (default)
• Previous Mode
• Pinpoint Type
• Target Trace Pinpoint
• Large ID Panel
• Navigation Tool
• Sensitivity Panel
• Coordinate View
• Target ID Panel
User Button Functions
Backlight
Backlight is the default function assigned to the User button; press to toggle the
backlight on and o.
If the backlight is not controlled by the User Button, it will automatically activate on
pressing a button as determined by backlight settings in the Options menu (page
49).
Previous Mode
Press to toggle between current and previous modes.
Pinpoint Type
Press to toggle between Normal and Sizing Pinpoint types.
Once the Pinpoint Type function is assigned to the User button it will also control
the Pinpoint settings in the Modes menu.
Target Trace Pinpoint
Press to toggle Target Trace Pinpoint on and o.
Large ID Panel
Press to toggle the Large ID Panel on and o.
Navigation Tool
Press to toggle the Navigation Tool on and o.
NOTE
Only the Backlight function can
be used from the menu screens.
All other User assigned functions
must be used from the Detect or
Map screens.

Minelab CTX3030 Specifications

General

Operating Frequency	1.5 kHz - 100 kHz
Display	Full color LCD
GPS	Yes
Wireless Audio	Yes
Waterproof	Up to 3 meters
Weight	5.2 lbs (2.36 kg)
Search Modes	Beach, Coin, Relic
Sensitivity Levels	Adjustable
Coil Size	11-inch
Target ID	0-50 scale
