Display Menu
CTX 3030 Instruction Manual
Display Menu
The Display menu is where you control which items you want to appear on the
Map and Detect screens.
Open the Display Menu
1. Press and hold the Menu button to display the Main Menu screen.
2. Use the arrow buttons to highlight the Display option and press Select to open the
Display menu.
Show or Hide Detect Screen Items
1. From the Display menu, use the down arrow button to highlight the Detect Screen
option and press Select.
The Detect options menu will be displayed with the following options:
• Large ID Panel (FE-CO)
• Navigation Tool
• Sensitivity Panel
2. Use the arrow and select buttons to highlight and select the item/s you want to
show.
A green tick will appear in the check box for each item selected.
3. Press the Detect button to return to the Detect screen.
The selected items will be visible.
Figure 33 – Detect screen showing optional items
Display
ʯ Show or hide Detect screen
items
ʯ Show or hide Map screen
items
NOTE
The large Target ID Panel will
only appear on the Detect screen
when a target is detected.

Minelab CTX3030 Specifications

General

Operating Frequency	1.5 kHz - 100 kHz
Display	Full color LCD
GPS	Yes
Wireless Audio	Yes
Waterproof	Up to 3 meters
Weight	5.2 lbs (2.36 kg)
Search Modes	Beach, Coin, Relic
Sensitivity Levels	Adjustable
Coil Size	11-inch
Target ID	0-50 scale
