7. Applications
MiR500 User guide (en) 09/2019 - v.1.3 ©Copyright 2018-2020: Mobile Industrial Robots A/S. 125
Bottom frame of the lift
1. Material: Steel (S355)
Thickness: 3 mm
Treatment: Powder coating RAL
7011
2. Areas marked with red indicate
where you are not allowed to
make modifications, such as
drilling holes or mounting
accessories.
NOTICE
The drawings above only show where you can make minor modifications
without damaging the product. You should not use it for any other
measurements or calculations.
