7. Applications
MiR500 User guide (en) 09/2019 - v.1.3 ©Copyright 2018-2020: Mobile Industrial Robots A/S. 124
7.2 Lift modifications
Additional holes can be added to the MiR500MiR500Pallet Lift for custom applications.
However, it is important not to damage any vital parts of the lift when doing so.
Top plate of the lift
1. Material: Steel (S355)
Thickness: 3 mm
Treatment: Powder coating RAL
9005
2. Areas marked with red indicate
where you are not allowed to
make modifications, such as
drilling holes or mounting
accessories.
