9. Payload specifications
MiR500 User guide (en) 09/2019 - v.1.3 ©Copyright 2018-2020: Mobile Industrial Robots A/S. 134
9. Payload specifications
The following drawings illustrate the center of mass (CoM) specifications for safe operation
with different payloads.
WARNING
Load falling or robot overturning if the load on MiR500 is not positioned or
fastened correctly.
• Ensure that the load is positioned according to the specifications and is
fastened correctly.
The specifications apply to payloads of up to 500 kg.
Side view 500 kg
