7. Applications
MiR500 User guide (en) 09/2019 - v.1.3 ©Copyright 2018-2020: Mobile Industrial Robots A/S. 119
7. Applications
You can install top modules on top of MiR500 for specific applications. For more information
about top modules, go to the following page:
http://www.mobile-industrial-robots.com/en/mir-tradeforum/
For instructions on how to mount top modules and accessories, refer to the application
manuals at www.mobile-industrial-robots.com or contact your distributor.
7.1 Mounting a top module
MiR500 has four M10M8 holes for mounting top modules as shown in Figure 7.1. The
tightening torque is 4718 Nm.
