3. Product presentation
MiR500 User guide (en) 09/2019 - v.1.3 ©Copyright 2018-2020: Mobile Industrial Robots A/S. 36
1. Not accessible; used for fixation of
the top cover.
3. M10 mounting holes for fixation
of top module, e.g.
MiR500EUPalletLift or
MiR500Pallet Lift.
For more information on
mounting top modules, see
Mounting a top module on
page119.
2. M12 lifting holes; one in each
corner. Used for fixation of
transportation eye bolts.
1. M8 mounting holes for fixation of top module.
For more information on mounting top modules, see Mounting a top
module on page119.
3.6 MiR500 internal parts
Most internal parts of MiR500 are reached through maintenance hatches that open to
different compartments:
• Front compartment
• Rear compartment
• Side compartments
• Top compartments
