Chapter 6 Programming 6-45
Setting Tray X-Pitch and Y-Pitch
Select
First part
X Reference
Y
Ref
ere
nce
Teaching.
Double click a desired cell (
Yes in
the figure
of the Program Editor
)
and move the camera to the
Teaching position to carry out
2-
position teaching.
