Chapter 4 Regular Chec4k- 4-37
2. The filter
assembly is at
the bottom right of the rear of the machine. Remove the
cover plate from the bottom right of the rear of the machine.
The filter replacement
period is subject to
change, depending on
the conditions of the
used air.
2. The filter
assembly is at
the bottom
right of the
rear of the
machine.
Remove the
cover plate
from the
bottom right of
the rear of the machine.
3. The filter assembly is inside the cover plate as shown in
the figure at the right. Turn the lower case 45 degrees and
remove it by pulling down.
4. The filter is inside the filter cover.
5. Check the filter element.
6. Clean the filter element using a suitable industrial
detergent and blow out the compressed air from the inside of
the element. Then, rinse it with water and dry.
7. If cleaning is not effective, replace the internal element. If
the filter element needs to be replaced, contact the MIrae
Customer Support Team.
Casting Off NG Part check
3.The filter assembly is installed inside the cover plate as shown
in the figure to the right. Loosen the bolt at the edge of the drain
catch to remove the filter cover from the upper case.
4.The filter is inside the filter cover.
5.Check the filter.
6.Clean the filter using a suitable industrial detergent and blow
out the compressed air from the inside the element. Then, rinse
it with water and dry.
7.If cleaning is not effective, replace the internal element. If the
filter needs to be replaced, contact the Mirae Customer Support
Team.
Air Filter Check Procedure
The drain collected in the filter case is automatically drained through
the drain valve. Since the filter element may be blocked by foreign
materials or its pressure may increase greatly during use, it should
be checked every 1 or 2 years and cleaned or replaced if
necessary.
Check Procedure
1. Unplug the machine.
