Positioning Head
• Types
The head picks up or places components using the nozzle attached at the
end of the header.
Head types include modular and precision heads.
• Functions
Modular Head: Suitable for high-speed placement of chip type
components and small leaded components. For instance, a 6-spindle
modular head can pick up or place 6 components at the same time.
Precision Head: Suitable for components requiring precision jobs such as
fine-pitch components and large leaded components.
• Placement System
One 6-spindle modular head is installed on the X gantry (or X-Frame) and
no precision head is used.
The modular head is suitable for high-speed placement of chip type
components and small leaded components.
Structure, features and specification of modular head are described below.
• Structure and Features
